MYP 0.66/1.14kV Mining Shielded Cable | Wear-Resistant and Anti-interference

1. Product Overview
MYp Mining Shielded Cable is specially designed for mobile equipment in underground coal mines. It adopts high elasticity tinned copper wire conductor + double layer metal shielding structure, which has excellent resistance to mechanical stress, oil and electromagnetic interference, and conforms to the international standards of GB/T 12972 and IEC, and it is suitable for the transmission of electric power of heavy equipment, such as coal mining machine, roadheader and conveyor.

2. Core Selling Points
Ultra-strong protection: galvanised steel wire braided shield + neoprene rubber sheath, tensile strength ≥15MPa, adapting to the complex underground environment.

Safety certification: MA coal mine safety certification, IEC 60502 standard, flame retardant grade IA.

Flexible and durable: the conductor adopts Category 5 tinned soft copper wire, bending radius ≤ 6 times the diameter of the cable, frequent movement without aging.

Efficient conductivity: 99.99% oxygen-free copper core, conductivity ≥ 98%, working temperature -40℃ to +90℃.

Customised service: support customised length and colour marking by metre, UL/CE and other international certifications available.

3. Technical Specifications
Item:Parameter details
Model:MYP 3×16+1×10+3×2.5(support customisation)
Rated voltage:0.66/1.14kV
Conductor material:Tin-plated annealed copper (in accordance with IEC 60228 Class 5)
Insulation: Ethylene Propylene Rubber (EPR) thickness 1.8mm±0.2mm
Shield: tinned copper wire braid coverage ≥ 85%
Sheath material: black neoprene (CR), thickness 3.0mm ± 0.3mm
Minimum bending radius: 6 x cable outer diameter

4. Application scenarios
Underground coal mine: comprehensive mining face equipment, mobile substation power supply system
Industrial field: harbour crane, shield machine, mining exploration equipment
Special environment: high humidity, strong electromagnetic interference, frequent bending scenes.
